Main Technical Parameter
Material: LDPE/PP Product: Shower ball, fruit and vegetable packing net, flower net Power: 35KW
Screw diameter: 65mm
Outside diameter of barrel: 105mm Screw L/D: 25:1
Screw material: 38CrMoALA Manpower needed: one person Layout: 10.0X3.0X2.0m
Specification
|
Model |
SHWJ-50 |
SHWJ-65 |
SHWJ-80 |
|
Screw diameter |
50mm |
65mm |
80mm |
|
Production Efficiency |
10-12kg/h |
20-30kg/h |
30-40kg/h |
|
Installed power |
25kw |
35kw |
50kw |
|
Machine weight |
1.8T |
2T |
3T |
Details Introduction
| Main motor power | 7.5 kw |
| Mode of main motor control | Frequency control of motor speed |
| Screw material | 38CrMoALA |
| Outside diameter of barrel | Φ105mm |
| Mode of speed change | Extruder dedicated reducer |
| Heating ring | Cast aluminum heater |
| Heating power | 12kw |
| Extruder head | High speed extruder head, frequency control of motor speed |
| Extruder head motor power | 4kw |
| Mode of extruder motor control | Frequency control of motor speed |
| Heating zone of extruder head | 2pcs |
| Heating power | 3kw |
| Sizing method | Size type |
| Cooling method | water cooling |
| Sizing width | according to customer requirement |
| Material of water tank | Stainless steel |
| Temperature control | electric heating water constant temperature control |
| Heating power | 9KW |
| Material of water tank | Stainless steel |
| Size | 2000×230×200mm |
| Tension power | 2.2KW |
| Driving type | Speed Converter |
| Reeling position | double position |
| Driving moment | 10N.M×2 |
| Dehydration power | 0.75KW |
Application
Packing & Delivery
Our Partner
Certifications
Company Information
Founded in 1994,Longkou Sunvo Packing Machinery Co.,Ltd is specialized in PE foam sheet production line ,PE foam tube/stick machine ,pe foam net machine ,ps food container production line,vacuumforming machine ,XPS foam board extrusion line etc.Our company enjoy great reputation with our products exported to Southeast Asia,he Middle East ,Central Asia,etc.
